| Parameters | Model |
| EBL08-12 | EBL10-20 | EBL15-26 | EBL20-28 | EBL25-30 |
| overall dimensions | Dimension L*W*H（mm） | 5100*1350*2580 | 5500*1750*2650 | 5800*1850*2750 | 6200*1960*2800 | 6500*2040*2800 |
| Wheelbase（mm） | 1910 | 2070 | 2315 | 2550 | 2675 |
| Wheelspan（mm） | 1100 | 1475 | 1500 | 1580 | 1630 |
| Min.ground clearance（mm） | 250 | 250 | 220 | 290 | 280 |
| Performance parameters | System pressure（MPa） | 16 | 16 | 16 | 18 | 18 |
| Vehicle weight（Kg） | 2200 | 3400 | 4800 | 5400 | 6000 |
| Maximum walking speed（Km/h） | 20 | 25 | 26 | 28 | 28 |
| Maximum climbing ability（°） | 25 | 25 | 25 | 25 | 25 |
| Maximum turning radius（mm） | 3000 | 3500 | 4000 | 4500 | 4500 |
| Excavation parameters | Maximum digging depth（mm） | 1500 | 2000 | 2700 | 2600 | 2600 |
| bucket loading height（mm） | 1500 | 1800 | 2200 | 2300 | 2300 |
| Max Digging Radius（mm） | 2000 | 2700 | 4600 | 4600 | 4600 |
| Bucket width（mm） | 350 | 400 | 600 | 600 | 600 |
| Bucket capacity（m³） | 0.08 | 0.1 | 0.2 | 0.2 | 0.25 |
| Maximum Digging Height（mm） | 2600 | 3300 | 4200 | 4300 | 4300 |
| Max. digging force（KN） | 25 | 25 | 28 | 28 | 28 |
| Excavator rotation angel（°） | 180 | 180 | 180 | 180 | 180 |
| Loading parameter | Max.unloading Height（mm） | 2200 | 2800 | 3300 | 3500 | 3500 |
| Max unloading Distance（mm） | 800 | 800 | 850 | 900 | 900 |
| loading bucket width（mm） | 1300 | 1800 | 1900 | 2100 | 2200 |
| loading bucket Capacity（m³） | 0.4 | 0.5 | 0.7 | 1 | 1.2 |
| Max lifting height（mm） | 3000 | 3300 | 4200 | 4300 | 4300 |
| Max rising force（KN） | 28 | 36 | 36 | 42 | 42 |
| face shovel（S） | 12 | 12 | 12 | 12 | 12 |
| Engine | Model | Changchai 390 | YN25GB | Yunnei YN27GBZ | YunneiYN38GBZ | Yunnei YN48GBZ |
| Type | 3 stroke（4 stroke） | direct injection, 4 stroke | turbocharge ,4 stroke | turbocharge ,4 stroke | turbocharge ,4 stroke |
| Rated power（KW） | 25（37） | 37 | 58 | 76 | 92 |
| Rated Rotary speed（r/min） | 2400 | 2400 | 2400 | 2400 | 2400 |
| Cylinder -Inside Diameter | 3-90（4-90） | 4-90 | 4-90 | 4-102 | 4-108 |
| Transmission System | Gearbox | Fixed shaft power shift | Fixed shaft power shift | Fixed shaft power shift | Fixed shaft power shift | Fixed shaft power shift |
| Gear number | Two Gears Ahead, Two Gears Astern | Two Gears Ahead, Two Gears Astern | Two Gears Ahead, Two Gears Astern | Two Gears Ahead, Two Gears Astern | Two Gears Ahead, Two Gears Astern |
| Fluid Torque Converter | ZL28F | ZL28F | ZL29A | ZL29A | ZL29A |
| Steering System | Type | Hinge Joint full-hydraulic steering | Hinge Joint full-hydraulic steering | Hinge Joint full-hydraulic steering | Hinge Joint full-hydraulic steering | Hinge Joint full-hydraulic steering |
| Steering Angel (°) | 33 | 33 | 33 | 33 | 33 |
| Axle | Type | 130 | ISUZU | wheel-side reducer | wheel-side reducer | wheel-side reducer |
| Tyre | Model | 825-16 | 20.5-16 | 23.5-16 | 16/70-20 | 16/70-20 |
| Front tyre pressure（KPa） | 250 | 250 | 250 | 250 | 250 |
| Rear tyre pressure（KPa） | 250 | 250 | 250 | 250 | 250 |
| Service braking system | Drum brake | Drum brake | Gas cap oil clamp disc brake | Gas cap oil clamp disc brake | Gas cap oil clamp disc brake |
| Parking barking system | Manual | Manual | Manual | Manual | Manual |
| Oil tank capacity | Diesel tank（L） | 20 | 30 | 40 | 50 | 50 |
| Hydraulic oil tank（L） | 20 | 30 | 40 | 50 | 50 |
| Other | Driving system | Four wheel driving | Four wheel driving | Four wheel driving | Four wheel driving | Four wheel driving |
| Transmission Pattern | Hydraulic transmission | Hydraulic transmission | Hydraulic transmission | Hydraulic transmission | Hydraulic transmission |
| Braking distance（mm） | 300 | 330 | 450 | 600 | 620 |
